How to Adjust Rotating Speed of Hammer Crusher Transmission Shaft?

Hammer crusher is widely applied in mining, building materials, chemical industry, metallurgy, feed and other industries. It can carry out medium and fine crushing of materials with less than100MPa compressive strength and less than 15% water content, such as barite, limestone, terrazzo, silicon sand, coal, coke, aluminum sulfate, gypsum, slag and so on. For the normal operation of hammer crusher, the rotating speed of the transmission shaft for per minute is very important. The transmission shaft speed of Ф 1300 type crusher is 485r / M (RPM) when it has full load. The size of belt pulley that drives the crusher is designed according to full load operation. Therefore, the speed is slightly higher when it is in empty load operation. Practice has proved that when the transmission shaft has correct speed, it can obtain the maximum yield and uniform product size.

The speed of the transmission shaft determines the amount of crushing materials and the times that materials are crushed in the crushing cavity. If the crusher cannot rotate according to the correct speed, it is better to adopt the one which is slightly higher than the correct speed (within five percent the correct speed). Because if the speed ratio is much lower than the standard, the accumulation of materials in the crushing cavity will increase or even lead to the stop of the crusher. For example, the standard of the shaft speed is 485r/m, and the rotation between 485 and 510rpm (485 x 1.05) does not affect the performance of the crusher.

In order to change the size and / or shape of the products, sometimes it is recommend using the speed which is slightly higher than the correct speed without changing the bypassing ability of the crusher. Usually, the higher speed is adopted together with a special eccentric sleeve with small eccentricity. Therefore, please ask the manufacturer for the correct speed of transmission shaft. Fote Machinery has complete types of hammer crushers for sale, which include heavy hammer crusher, ring hammer crusher, mini hammer crusher and so on. Through years of production experience, we have continuously updated out production technology to bring more benefits for customers!
